DIN Cast Iron Angle Globe Valve manufacturers, globe valve kitz


Name:DIN Cast Iron Angle Globe Valve manufacturers, globe valve kitz
Design confirms:DIN3356
Flanges drilled confirms:BS EN1092
Tightness check:EN12266
Face-to-face conform:BS EN558-1 series 1
Normal pressure:1.6MPa
Shell test pressure:2.4Mpa
Seal test prressure:1.76Mpa
Suitable medium:water and neutral liquid
Working temperature:0 to 120 centigrade.
Body/Bonnet/Disc:Cast iron GG25
DISC:Cast iron with Brass or stainless steel seal ring
Stem:Zinc Plated Steel/ Stainless Steel/ 2Cr13 stainless steel etc.
GLAND FLANGE:Cast iron GG25

  • DIN Cast Iron Angle Globe Valve manufacturers, globe valve kitz
