JIS F 7471 cast steel 4 globe valves cv, globe valve dimensions
| Name: | JIS F 7471 cast steel 4 globe valves cv, globe valve dimensions |
| Design confirms: | JIS F7471 |
| Flanges drilled confirms: | JIS 5K/10K/16K |
| Tightness check: | JIS F7471 |
| Face-to-face conform: | JIS F7471 |
| Normal pressure: | 0.98MPa/1.56MPa |
| Shell test pressure: | 1.47MPa/2.34MPa |
| Seal test prressure: | 1.18MPa/1.87MPa |
| Suitable medium: | water and neutral liquid |
| Working temperature: | -20 to 425 centigrade |
| Body/Bonnet/Disc: | SC480 |
| DISC: | CAC406(BC6) or SCS2 |
| Stem: | SUS403 |
| GLAND FLANGE: | SC480 |
