DIN Cast Steel float air actuated ball valve components, grainger ball valve


Name:DIN Cast Steel float air actuated ball valve components, grainger ball valve
Design confirms:DIN3357
Flanges drilled confirms:DIN2501/EN1092-2 PN10/16/25
Tightness check:API 598/ISO 5208/EN12226-1
Face-to-face conform:DIN3202,F6/EN558-1 series 48
Normal pressure:1.6MPa
Shell test pressure:2.4Mpa
Seal test prressure:1.76Mpa
Suitable medium:water and neutral liquid
Working temperature:≤200℃
Body/Bonnet/Disc:WCB
Seat:PTFE
Stem:SS304
Ball:SS304
