ANSI Class150 2 1 2 Ball Valve, flow control ball valve, leaking 0 ball valve
| Name: | ANSI Class150 2 1 2 Ball Valve, flow control ball valve, leaking 0 ball valve |
| Design confirms: | ANSI B16.34 |
| Flanges drilled confirms: | ANSI B16.5 |
| Tightness check: | API 598/ISO 5208/EN12226-1 |
| Face-to-face conform: | ANSI B16.10 |
| Normal pressure: | 150LB |
| Shell test pressure: | 3.75Mpa |
| Seal test prressure: | 2.75Mpa |
| Suitable medium: | water and neutral liquid |
| Working temperature: | ≤200℃ |
| Body/Bonnet/Disc: | WCB |
| Seat: | PTFE |
| Stem: | SS304 |
| Ball: | SS304 |
