| Name: | F7306/7308/7310 Cast iron angle type globe valve for steam 2CR13, globe control valve manufacturer |
| Design confirms: | JIS F7306/7308/7310 |
| Flanges drilled confirms: | JIS 5K/10K/16K |
| Tightness check: | JIS F7306/7308/7310 |
| Face-to-face conform: | JIS F7306/7308/7310 |
| Normal pressure: | 0.49MPa/0.98MPa/1.56MPa |
| Shell test pressure: | 0.74Mpa/1.47MPa/2.34MPa |
| Seal test prressure: | 0.59Mpa/1.18MPa/1.87MPa |
| Suitable medium: | water and neutral liquid |
| Working temperature: | 0 to 200 centigrade. |
| Body/Bonnet/Disc: | FC200 or FCD400 |
| DISC: | BC6; or brass or Stainless Steel 2CR13 or 1CR13 |
| Stem: | Brass C3771BD; or Stainless Steel 2CR13 or 1CR13. |
| GLAND FLANGE: | FC200 or FCD400 |
|
|
